6809RS Bearing 45x58x7mm - Sealed Ball Bearing

6809RS Sealed Slim Ball Bearing
✔️ 45mm ID × 58mm OD × 7mm Wide - EMQ Chrome Steel

The 6809RS is a slim-section deep groove ball bearing, sealed on both sides with rubber for long-lasting protection. Built from durable chrome steel and pre-lubricated with grease, it’s perfect for compact, high-speed applications like electric motors, gearboxes, and robotics.

✅ Inner diameter: 45mm
✅ Outer diameter: 58mm
✅ Width: 7mm
✅ Material: Chrome steel
✅ Balls: Chrome steel
✅ Cage: Steel
✅ Seals: Double rubber seals (RS)
✅ Clearance: C0 (standard)
✅ Dynamic load rating (Cr): 5,350 N
✅ Static load rating (Cor): 4,900 N
✅ Max speed (grease): 6,000 RPM
✅ Type: Deep groove radial ball bearing
✅ Quality: Electric motor grade (EMQ)
✅ Pack size: 1 bearing

Dimensions Table:

Equivalent to:
✅ 6809-2RS1
✅ 6809-2RZ
✅ 61809RS1
